PUMO electric cylinder is a device that converts electrical energy into high-precision linear motion and is gradually replacing traditional hydraulic and pneumatic cylinders in many situations.

PUMO electric cylinder is essentially a combination of servo motor and screw. The motor rotates and is driven by a screw to transform the rotational motion into linear extension and contraction of the push rod. Compared to hydraulic/pneumatic, its system is extremely simple, requiring only the motor, cylinder body, controller, and cables to operate.

core advantage

Compared to traditional methods, PUMO electric cylinders have prominent advantages:

·Ultra high precision: The repeated positioning accuracy can reach ± 0.01mm, and some high-precision products can even reach the micrometer level. It can also provide real-time feedback on position and thrust.

·Energy saving and environmental protection: only consumes power during operation, not at rest; And there is no need for hydraulic oil, no leakage pollution.

·Simple structure: eliminates complex pump stations, pipelines, and valves, making maintenance easy.

2. There are significant differences in parameters among different models, roughly ranging from:

·Thrust: from tens of kilograms to over 100 tons (1000kN).

·Speed: generally ranging from 0.1 to 2 m/s, with a maximum of over 1.6 m/s.

·Itinerary: Usually 1-2500mm, special can be customized.

3. PUMO electric cylinder is widely used:

·Industrial automation: robots, production lines, automotive parts pressing.

·Testing and simulation: material pressure testing, flight/driving simulator.

·High end manufacturing: precision machine tools, 3D printing, semiconductor equipment.

·Special fields: military equipment, aerospace testing, medical instruments (such as CT).
